Productdetails:
|
Materiaal: | U71Mn | Gewicht: | 50,4 kg/m² |
---|---|---|---|
Lengte: | 10-25m | Standaard: | JIS E1103-93/JIS E1101-93 |
Hoog licht: | JIS 50N stalen spoorrail,JIS 50KG stalen spoorrail,U71Mn stalen kraanrail |
De JIS E 1101-2001 standaard 50N spoorrail is de Japanse standaardrail.Lengte kan 12-30 meter zijn, hardheid R260 of R350HT.
Specificatie
Standaard | JIS E1103-93/JISE1101-93 | ||||||
Model | DIMENSIE | Gewicht | Materiaal | Lengte | |||
EEN (mm) | B(mm) | C(mm) | t(mm) | (KG/M) | (m/pc) | ||
JIS 50N | 65 | 153 | 127 | 15 | 50.4 | U71Mn | 10-25 |
Tekening
